Product Features:
(1) Single mast aluminum lifting platform suitable for: Single people aerial working.
(2) Mast structure is made of high strength extruding aluminum alloy, safe and light weight.
(3) Compact structure, can enter into narrow passageways and elevator doors.
(4) Using self-developed integral built-in slider between the masts, minimize the dynamic gap between the masts, and making lifting and lowering with more smooth, reliable, far better than ordinary independent guide wheel support structure.
(5) Lifting chains use double-stranded structure, which are industrial plate chains, with great capacity and high safety factor. Fence structure as a whole is of collection type, the operation of which is extremely simple and convenient.
(6) Integral hydraulic power unit, compact structure, reliable performance. Setting with emergency lowering device under power-off state to guarantee the safety for emergency.
(7) Device control voltage is DC 24V, effectively guarantee the personal safety; devices with leakage protection switch, emergency stop switches, limit switches, etc., buttons, boxes are waterproof design.

Standard configuration:
(1)Maximum height Specifications: Optional 4m, 6m, 8m, 9m.
(2) Power supply: single-phase AC power (AC220V/50HZ), other forms are optional.
(3) Move: Manual traction.

Optional configuration:
(1)DC battery-powered.
(2) AC and DC powered.
(3) Can be installed on the pickup, light truck and other auto compartment (vehicle-mounted), customers need to bring their own vehicles and provide car data.
(4)The trailer chassis is available, suitable for the large distance drag occasions.
(5) Insulated platform is also available. (Used in power distribution house for example)
(6)Electrical explosion-proof lifts, used in oil and natural gas explosion-proof requirements occasions.
