Self-propelled Scissor Lift is a kind of aerial working equipments which use battery or other power to realize moving, steering and lifting instead of manpower, widely used in modern aerial working occasions, for example, in workshop, hotel, stadium, hospital, and so on. Not only it owns general characteristics of scissor lifts, but also it has the following advantages:
(1) Self-propelled function, without external traction, move or turn easily and flexibly.
(2) Proportional controls for lifting and driving functions.
(3) The platform can outreach 1m.
(4) Manual emergency lowering valve, even no power, the machine can safely lower down.
(5) Automatic 25A battery charger provides strong power for vehicle.
(6) Emergency stops both platform and ground.
(7) Manual brake release function can move the machine under the circumstances without power and forklift.
(8) Self-protection when driving on rough roads.
(9) Battery charge indicator.
(10) Non- marking tires make sure there is no damage and no marks on the ground.
(11) AC power supply connecting to the platform.
(12) Safety maintenance supporting bars.
(13) Buzzer for the warning use.
(14) Standard forklift pockets.
(15) Diagnosis system on the machine.
Model |
GTJZ06A |
GTJZ-6 |
GTJZ-8 |
GTJZ-10 |
GTJZ-12 |
GTJZ-14 |
GTJZ-16 |
Max working height |
8.00m |
8.00m |
10.00m |
12.00m |
14.00m |
16.00m |
18.00m |
Max platform height |
6.00m |
6.00m |
8.00m |
10.00m |
12.00m |
14.00m |
16.00m |
Total capacity |
230kg |
450kg |
450kg |
320kg |
320kg |
230kg |
230kg |
Extend platform load |
113kg |
113kg |
113kg |
113kg |
113kg |
113kg |
113kg |
Platform size |
1.68×0.78m |
2.27×1.13m |
2.27×1.13m |
2.27×1.13m |
2.27×1.13m |
2.64×1.13m |
3.05×1.13m |
Overall length |
1.82m |
2.47m |
2.47m |
2.47m |
2.47m |
2.84m |
3.18m |
Overall width |
0.78m |
1.16m |
1.15m |
1.18m |
1.16m |
1.4m |
1.51m |
Height guardrail folded |
2.02m |
2.19m |
2.29m |
2.45m |
2.58m |
2.58m |
2.85m |
Height guardrail raised |
1.62m |
1.61m |
1.84m |
1.87m |
1.99m |
1.99m |
2.18m |
Platform Extension |
0.9m |
0.9m |
0.9m |
0.9m |
0.9m |
0.9m |
0.9m |
Ground clearance |
0.1/0.02m |
0.1/0.02m |
0.1/0.02m |
0.1/0.02m |
0.1/0.02m |
0.1/0.02m |
0.1/0.02m |
Wheelbase |
1.36m |
1.89m |
1.89m |
1.89m |
1.89m |
2.26m |
2.40m |
Turning radius |
0/1.7m |
0/2.2m |
0/2.2m |
0/2.2m |
0/2.2m |
0/2.7m |
0/3.1m |
Motor Power |
24V/3.4kw |
24V/4.5kw |
24V/4.5kw |
24V/4.5kw |
24V/4.5kw |
24V/4.5kw |
24V/4.5kw |
lifting speed |
3-5m/min |
3-5m/min |
3-5m/min |
3-5m/min |
3-5m/min |
3-5m/min |
3-5m/min |
Speed collapsed state |
3.5km/h |
3.5km/h |
3.5km/h |
3.5km/h |
3.5km/h |
3.5km/h |
3.5km/h |
Speed rising state |
0.8km/h |
0.8km/h |
0.8km/h |
0.8km/h |
0.8km/h |
0.8km/h |
0.8km/h |
Storage battery |
4×6V/225ah |
4×6V/225ah |
4×6V/225ah |
4×6V/225ah |
4×12V/300ah |
4×12V/300ah |
4×12V/300ah |
Charger |
24V/30A |
24V/30A |
24V/30A |
24V/30A |
24V/30A |
24V/30A |
24V/30A |
Gradeability |
25% |
25% |
25% |
25% |
25% |
25% |
25% |
Max allowable angle |
1.5°/3° |
1.5°/3° |
1.5°/3° |
1.5°/3° |
1.5°/3° |
1.5°/3° |
1.5°/3° |
Moving Wheel |
Φ381×127mm |
Φ381×127mm |
Φ381×127mm |
Φ381×127mm |
Φ381×127mm |
Φ381×127mm |
Φ381×127mm |
Weight |
1550kg |
2200kg |
2350kg |
2650kg |
3050kg |
3390kg |
4650kg |
Thanks for your visit Marle website! You can get our detailed service plan from this part. If you have any questions or suggestions when you are purchasing lifts, you can always contact us through the following ways. Marle professional engineers will provide a full range of consulting attentive service and solve problems in the first time to ensure that each customer can purchase satisfied products.
For advisory services: please call 0512-65801131;
For technical support: please call 0512-65801132;
If you need to send procurement requirements: Please send a fax 0512-65801135;
You can also send mail for more product information: sales@chinamarle.com
If the products can not be used as a result of product quality problems, we promise that:
(1) Return the product within ten days after receiving;
(2) Replace the product within one month after receiving;
(3) One-year warranty.
