Product Features:

(1) Three masts aluminum lifting platform form a triangular structure, more stable, and greater capacity;
(2)  Four masts aluminum lifting platform can reach up to higher, and big capacity;
(3)  Six masts aluminum lifting platform uses 2 +1 form, four-poster masts at the bottom, two-poster masts on the top, max height of which can reach up to 25m.
(4)  Mast structure is made of high strength extruding aluminum alloy, safe and light weight.
(5)  Using self-developed integral built-in slider between the masts, minimize the dynamic gap between the masts, and making lifting and lowering with more smooth, reliable, far better than ordinary independent guide wheel support structure.
(6)  Lifting chains use double-stranded structure, which are industrial plate chains, with great capacity and high safety factor.
(7)  Fence structure as a whole is of collection type, the operation of which is extremely simple and convenient.
(8)  Integral hydraulic power unit, compact structure, reliable performance. Setting with emergency lowering device under power-off state to guarantee the safety for emergency.
(9) Device control voltage is DC 24V, effectively guarantee the personal safety.
(10) Leakage protection switch, emergency stop switches, limit switches, etc., buttons, boxes are waterproof design.

Standard configuration:

(1)  Maximum height Specifications: From 10m to 25m.
(2)  Power supply: single-phase AC power (AC220V/50HZ), other forms are optional.
(3)  Move: Manual traction.

Optional configuration:

(1)  Self-propelled device is available.
(2)  Movable platform, max extended length is 800mm.
(3)  Insulated platform is also available. (Used in power distribution house for example)
(4)  Electrical explosion-proof lifts, used in oil and natural gas explosion-proof requirements occasions.
