Aluminum Aerial Work Platform Rental
Home > Rent > Aluminum Aerial Work Platform Rental |
 |
Aluminum lift is a new generation design aerial equipment, with compact structure, clear appearance, safe, reliable, energy saving and environmental protection. The mast structure is made of high strength aluminum alloy extrusion, which has excellent lifting capacity in a very small space. This series are widely used in factories, hotels, buildings, shopping malls, railway stations, airports, stadiums and so on. It also can be used in aerial working applications such as power lines, lighting, appliances, elevated pipelines installation and maintenance, cleaning, etc.
| Series | Model | Max Platform Height(m) |
Max Working Height(m) |
Capacity (kg) |
Platform Size (m) |
Dimensions (L*W*H)(m) |
Weight (kg) |
Power Source (v/hz) |
| Sigle Mast |
GTWY4-100 | 4 | 5.7 | 125 | 0.6*0.55 | 1.28*0.76*1.62 | 245 | AC220/50 |
| GTWY6-100 | 6 | 7.7 | 125 | 0.6*0.55 | 1.28*0.76*1.98 | 275 | AC220/50 | |
| GTWY8-100 | 8 | 9.7 | 125 | 0.6*0.55 | 1.28*0.76*1.98 | 295 | AC220/50 | |
| GTWY9-100 | 9 | 10.7 | 125 | 0.6*0.55 | 1.35*0.82*1.98 | 310 | AC220/50 | |
| Double Masts |
GTWY6-200S | 6 | 7.7 | 200 | 1.17*0.67 | 1.34*0.85*1.98 | 405 | AC220/50 |
| GTWY8-200S | 8 | 9.7 | 200 | 1.17*0.67 | 1.34*0.85*1.98 | 465 | AC220/50 | |
| GTWY9-200S | 9 | 10.7 | 200 | 1.37*0.67 | 1.55*0.95*1.98 | 475 | AC220/50 | |
| GTWY10-200S | 10 | 11.7 | 200 | 1.37*0.67 | 1.55*0.95*1.98 | 585 | AC220/50 | |
| GTWY12-200SA | 12 | 13.7 | 200 | 1.49*0.67 | 1.67*1.00*1.98 | 640 | AC220/50 | |
| GTWY12-200SB | 12 | 13.7 | 200 | 1.27*0.67 | 1.55*0.95*2.25 | 640 | AC220/50 | |
| Three Masts |
GTWY10-300S | 10 | 11.7 | 200 | 1.52*0.92 | 1.92*1.17*2.05 | 865 | AC220/50 |
| GTWY12-300SA | 12 | 13.7 | 200 | 1.52*0.92 | 1.80*1.17*2.30 | 960 | AC220/50 | |
| GTWY12-300SB | 12 | 13.7 | 200 | 1.64*0.92 | 1.80*1.17*2.05 | 960 | AC220/50 | |
| GTWY14-300SA | 14 | 15.7 | 200 | 1.64*0.92 | 1.92*1.17*2.30 | 1020 | AC220/50 | |
| GTWY14-300SB | 14 | 15.7 | 200 | 1.52*0.92 | 1.80*1.17*2.55 | 1020 | AC220/50 | |
| Four Masts |
GTWY10-400S | 10 | 11.7 | 300 | 1.40*0.80 | 1.70*1.10*2.05 | 950 | AC220/50 |
| GTWY12-400S | 12 | 13.7 | 300 | 1.40*0.80 | 1.70*1.10*2.32 | 980 | AC220/50 | |
| GTWY14-400SA | 14 | 15.7 | 300 | 1.40*0.80 | 1.80*1.10*2.52 | 1000 | AC220/50 | |
| GTWY14-400SB | 14 | 15.7 | 300 | 1.40*0.80 | 1.90*1.10*2.32 | 1000 | AC220/50 | |
| GTWY15-400S | 15 | 16.7 | 200 | 1.40*0.80 | 2.00*1.20*2.68 | 1100 | AC220/50 | |
| Six Masts |
GTWY16-4200S | 16 | 17.7 | 160 | 1.45*0.90 | 2.25*1.30*2.18 | 1200 | AC220/50 |
| GTWY18-4200S | 18 | 19.7 | 160 | 1.45*0.90 | 2.25*1.30*2.42 | 1400 | AC220/50 | |
| GTWY19-4200S | 19 | 20.7 | 160 | 1.55*0.90 | 2.50*1.40*2.52 | 1500 | AC220/50 | |
| GTWY20-4200S | 20 | 21.7 | 160 | 1.55*0.90 | 2.50*1.40*2.62 | 1780 | AC220/50 | |
| GTWY22-4200S | 22 | 23.7 | 160 | 1.55*0.90 | 3.00*1.60*2.82 | 1880 | AC220/50 |
